神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (08-011) - PANEL ASSY, INST P/N 24100J3808F6 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
866 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J3808F6 | [1] | PANEL ASSY, INST | |
| 2. | 2416J616 | [1] | BRACKET | |
| 4. | 2489U136 | [1] | SWITCH | KOB |
| 5. | 2489U142 | [1] | HOURMETER | KOB, Serial Range: LE3401-LE3924 |
| 6. | 2420T2635 | [1] | GROMMET | KOB |
| 7. | 2456R149F1 | [1] | LAMP | KOB |
| 7-8. | 4856Z20D1 | [1] | CLAMP | |
| 10. | P27P0008 | [1] | TRAY, ASH | |
| 11. | 2480U142 | [1] | HOUR-METER | |
| 13. | P79T0054 | [1] | SWITCH | |
| 14. | P79T001 | [1] | SWITCH | |
| 15. | P79T0058 | [1] | SWITCH, HEATER | |
| 16. | 2479R243F1 | [1] | FUSE BOX | KOB |
| 16-3. | 2479R243S1 | [1] | FUSE | KOB |
| 17. | 24100P376F5 | [1] | LEVER ASSY THROTTLE | LEVER ASSY THROTTLE |
| 17-1. | 2406P1125 | [1] | LEVER | LEVER |
| 17-2. | B16P0275 | [1] | BRACKET | KOB |
| 17-3. | P16T0076 | [1] | WASHER | |
| 17-4. | P16T0040 | [1] | WASHER | |
| 17-5. | NSS | [1] | NOT SOLD SEPARAT | CONWASHER |
| 17-6. | NSS | [1] | NOT SOLD SEPARAT | CONGRIP |
| 17-7. | ZN11C12007 | [1] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12007 |
| 18. | NSS | [1] | NOT SOLD SEPARAT | CONSPEAKER |
| 19. | 2416N2255D2 | [1] | PANEL | PANEL |
| 20. | 4079Z22 | [1] | RELAY | KOB |
| 21. | NSS | [1] | NOT SOLD SEPARAT | CONGROMMET |
| 22. | NSS | [1] | NOT SOLD SEPARAT | CONGROMMET |
| 24. | R16T0402D1 | [1] | CLAMP | KOB |
| 25. | NSS | [2] | NOT SOLD SEPARAT | CONSEMS- BOLT |
| 26. | ZS16C12020 | [2] | KEY | KOBM12x1.75x20mm Superseded by part number: ZS18C12020 |
| 27. | ZW26X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 28. | NSS | [5] | NOT SOLD SEPARAT | CONSEMS-BOLT |
| 29. | NSS | [10] | NOT SOLD SEPARAT | CONSEMS-BOLT |
| 30. | ZS31C06012 | [6] | SCREW,Phillips Drive, Pan HD, M6 x 12mm | KOBM06x1.0x12mm |
| 31. | NSS | [4] | NOT SOLD SEPARAT | CONSEMS-BOLT |
| 32. | 2479Z214 | [1] | CIGARETTE LIGHTER | KOB |
| 33. | ZW16X10000 | [3] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 34. | 2418T5373C2 | [2] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 35. | ZW16X06000 | [10] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 36. | NSS | [2] | NOT SOLD SEPARAT | CONWASHER |
| 37. | NSS | [6] | NOT SOLD SEPARAT | CONLOCK WASHER |
| 38. | ZW26X05000 | [4] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 56. | 2416N2373 | [1] | BRACKET | |
| 57. | NSS | [1] | NOT SOLD SEPARAT | CONCABLE ASSY, STOP |
| 59. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET |
| 60. | NSS | [1] | NOT SOLD SEPARAT | CONCABLE CONTROL |
| 60-4. | NSS | [1] | NOT SOLD SEPARAT | CONROD-END |
| 60-5. | B16T0175 | [1] | PIN | |
| 60-6. | NSS | [1] | NOT SOLD SEPARAT | CONSPLIT PIN |
| 66. | NSS | [1] | NOT SOLD SEPARAT | CONGAUGE, OIL PRESS, Start Serial: LE3925- |
| 9. | VI98271022700 | [1] | STARTER SWITCH, ISUZU ENGINE PARTS | |
| 23. | VI9825301080 | [1] | RESISTOR | KOBCONTROL, ISUZU ENGINE PARTS |
| 47. | VI1825530110 | [1] | RELAY | KOBSAFETY RELAY, ISUZU ENGINE PARTS Superseded by part number: 1825530110 |
| 61. | VI18125102600 | [1] | REGULATER, ISUZU ENGINE PARTS | |
