凯斯零件查询(LB424R) - BALER (9/12-) (71.480.020) - OIL PUMP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
379 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84818518
|
[1] |
LUBE PUMP
|
BEL
Incl 25 - 32
|
| 2. |
86512439
|
[2] |
CARRIAGE BOLT,M6 x 16mm, Cl 8.8
|
NH
|
| 3. |
84818662
|
[1] |
SUPPORT
|
ZED
|
| 4. |
335021
|
[2] |
CLAMP,12mm ID, 6.4mm Bolt Hole, P Type
|
ZED
|
| 5. |
84818517
|
[2] |
BRUSH
|
ZED
|
| 6. |
378243
|
[4] |
WASHER,8.4mm ID x 21mm OD x 1.6mm Thk
|
NH
Superseded by part number: 63707, 63707, 86625263
|
| 7. |
43128
|
[2] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 8. |
86629542
|
[2] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 9. |
86566990
|
[11] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 10. |
322357
|
[4] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 11. |
412152
|
[4] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 12. |
43117
|
[2] |
SCREW,Hex, M6 x 1.0 x 30mm, Cl 8.8
|
NH
Superseded by part number: 87317695
|
| 13. |
120100
|
[2] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 14. |
9706755
|
[2] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 15. |
86590413
|
[2] |
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
|
ZED
|
| 16. |
445394
|
[2] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 17. |
84818521
|
[1] |
MANIFOLD
|
ZED
|
| 18. |
9832305
|
[1] |
WASHER,10mm ID x 14mm OD x 1.5mm Thk
|
ZED
|
| 19. |
84807296
|
[1] |
PLUG
|
ZED
|
| 20. |
84819098
|
[1] |
HYD CONNECTOR
|
ZED
|
| 21. |
47910681
|
[1] |
HOSE
|
ZED
Hose, D = 4 MM
|
| 22. |
84818520
|
[1] |
HOSE
|
ZED
Hose, D = 8 MM
|
| 23. |
84807243
|
[2] |
HYD CONNECTOR
|
ZED
|
| 24. |
87344244
|
[2] |
REDUCER
|
ZED
End Fitting
|
| 25. |
84818525
|
[1] |
HYDRAULIC OIL FILTER
|
ZED
|
| 26. |
84819466
|
[1] |
HYDRAULIC OIL FILTER
|
ZED
|
| 27. |
84819100
|
[1] |
HYDRAULIC VALVE
|
ZED
|
| 29. |
84819099
|
[1] |
HYDRAULIC PUMP,12V
|
ZED
|
| 30. |
84819467
|
[1] |
WIRE HARNESS
|
ZED
|
| 31. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Housing Incl in 1
|
| 32. |
84801563
|
[1] |
FILLER CAP
|
ZED
|
