纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-45-00[01]) - GUARD INSTALLATION, (STANDARD) (YT21C00021F2), PAGE 1 OF 2 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
395 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT21C01866F1 | [1] | GUARD | KOBGuard Assembly, Incls. Refs. 1-1 -1-22 |
| 1-1. | YT21C01865P1 | [1] | GUARD | KOB |
| 1-2. | YR21C01414P1 | [1] | INSULATION | KOBInsulation |
| 1-3. | YT21C01635P1 | [1] | Insulation | |
| 1-4. | YR21C01415P1 | [1] | INSULATION | KOBInsulation |
| 1-8. | YT21C01641P1 | [1] | RUBBER SEAL | KOB |
| 1-9. | YT21C01651P1 | [1] | INSULATION | KOBInsulation |
| 1-10. | YT21C01164DL | [1] | WEATHERSTRIP | KOB |
| 1-11. | YT21C01164DM | [1] | WEATHERSTRIP | KOB |
| 1-12. | YR21C01168D2 | [1] | WEATHERSTRIP | KOB207mm Long (8-9/64 in) |
| 1-13. | YJ21C01103D5 | [1] | WEATHERSTRIP | KOB |
| 1-14. | YR21C01168DE | [1] | WEATHERSTRIP | KOB140mm Long (5-1/2 in) |
| 1-15. | YR21C01423P1 | [1] | INSULATION | KOBInsulation |
| 1-16. | YT21C01693P1 | [1] | INSULATION | KOBInsulation |
| 1-18. | YR21C01424P1 | [1] | INSULATION | KOBInsulation |
| 1-19. | YN21C01136D6 | [1] | STRIP | KOBWeather |
| 1-20. | PY21C01007DH | [1] | WEATHERSTRIP | KOB |
| 1-21. | YR21C01437P1 | [1] | INSULATION | KOBInsulation |
| 1-22. | YR21C01168DJ | [1] | WEATHERSTRIP | KOB165mm Long (6-1/2 in) |
| 6. | YF21C01765P1 | [1] | SPRING | KOB |
| 7. | ZM73C08016 | [5] | BOLT,M8x16mm - Course Thread | KOBM08x1.25x16mm (Incls. Washer) |
| 8. | ZM73C12025 | [14] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
| 12. | YR21C01425F1 | [1] | BRACKET | KOBBracket Assembly, Incls. Refs. 12-1 & 12-2 |
| 12-1. | YR21C01426P1 | [1] | BRACKET | KOB |
| 12-2. | YR21C01168DC | [1] | WEATHERSTRIP | KOB50mm Long (1-31/32 in) |
