纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-45-00[02]) - GUARD INSTALLATION, (STANDARD) (YT21C00021F2), PAGE 2 OF 2 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
240 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | YT21C01632F1 | [1] | GUARD | KOBGuard Assembly, Incls. Refs. 2-1 & 2-2 |
| 2-1. | YT21C01951P1 | [1] | GUARD | KOB |
| 2-2. | YR21C01168DK | [1] | RUBBER SEAL | KOBWeatherstrip -- 360mm Long (14-11/64 in) |
| 3. | YT21C01652P1 | [2] | BRACKET | KOBBracket |
| 4. | YT21C01823F1 | [1] | Pillar Assembly, Incls. Refs. 4-1 & 4-2 | |
| 4-1. | YT21C01944P1 | [1] | PILLAR | KOB Superseded by part number: YT21C01976P1 |
| 4-2. | YT21C01822P1 | [1] | RUBBER SEAL | KOB |
| 5. | YT21C01941P1 | [1] | BRACKET | KOB |
| 7. | ZM73C08016 | [5] | BOLT,M8x16mm - Course Thread | KOBM08x1.25x16mm (Incls. Washer) |
| 8. | ZM73C12025 | [14] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
| 9. | ZM73C12030 | [2] | BOLT,M12x30mm - Course Thread | KOBM12x1.75x30mm (Incls. Washer) |
| 13. | YT21C01809P1 | [1] | SUPPORT | KOB |
| 14. | YT21C01812P1 | [1] | PLATE | KOBPlate |
| 15. | ZS18C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 16. | ZW26X12000 | [2] | WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 17. | YN27C01006P1 | [2] | WASHER | KOB |
