纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-56-00[00]) - CONTROLLER INSTALLATION (YT22E00057F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
586 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | VI5825500300 | [1] | RELAY | KOBEngine Parts 09-00-00 |
| A2. | VI8980305740 | [1] | CONTROLLER | KOBEngine Parts 09-00-00 |
| A3. | VI1825530391 | [1] | RELAY | KOBEngine Parts 09-00-00 |
| A4. | YT22E01093P1 | [1] | Support | |
| A5. | YT22E01152P1 | [1] | Support | |
| A6. | YT22E01100P2 | [1] | Support | |
| A7. | YN50S00047P1 | [1] | TOGGLE SWITCH | KOBToggle (Swing Parking Brake Release) |
| A8. | YN22M01014P1 | [1] | LABEL | KOBDecal, Release Lock and Normal |
| A9. | ZM61C06016 | [9] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| A10. | ZM61C06020 | [4] | BOLT | KOBM06x1.0x20mm (Incls. Washer & Lockwasher) |
| A11. | ZM61C06025 | [3] | BOLT | KOBM06x1.0x25mm (Incls. Washer & Lockwasher) |
| A12. | ZM73C08020 | [2] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| A13. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBM08x1.25x25mm (Incls. Washer) |
| A14. | YT22E01134P1 | [4] | CAPTIVE WASHER SCREW | KOB |
| . . | YT22E00063F1 | [1] | CONTROLLER | KOBAssembly incl. ref. B1,B2 Superseded by part number: YT22E00063F5 |
| B1. | YN22E00214F1 | [1] | CONTROL | KOBNo Software installed Superseded by part number: YN22E00425F1 |
| . . | YN22E00425F1R | [1] | REMAN-ELECTRONIC CONTROL UNIT | KOBE70B TIER 4 (4/08-), Reman For New P/N YN22E00214F1 |
| . . | YN22E00425F1C | [1] | CORE-ELECTRONIC CONTROL UNIT | KOBReturn Number |
| B2. | NA | [1] | NOT SERVICED | FOR |
| C1. | YY24E00008F2 | [1] | BOX, FUSE | KOBRelay Assembly -- See Figure 02-57-00 |
| C2. | YT73E01013P2 | [1] | DECAL | KOBLabel |
| C3. | YT73E01014P1 | [1] | DECAL | KOBLabel |
| D1. | YY24S00001P2 | [1] | RELAY | KOBFlasher |
| D2. | YT22E01121P1 | [1] | Support | |
| E1. | YT77S00001P1 | [1] | CONVERTER,24V In - 12V Out - 2.5A | KOB Superseded by part number: YT77S00011P1 |
