纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-46-00[00]) - COVER ASSEMBLY, UNDER (YT24C00009F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
564 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT24C01046P1 | [1] | COVER | KOB |
| 2. | YT24C01052P1 | [1] | COVER | KOBCover |
| 3. | YT24C01048P1 | [1] | COVER | KOBCover |
| 4. | YT24C01045P1 | [1] | COVER | KOBCover |
| 5. | YT24C01041P1 | [1] | COVER | KOBCover |
| 6. | YT24C01042P1 | [1] | COVER | KOBCover |
| 7. | ZM73C12025 | [30] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
