| 1. | HX11W08210DX | [2] | FLEXIBLE HOSE | KOB |
| 4. | YN20M01494D7 | [1] | BELT | KOBV-Belt -- 1054mm Long (41-1/2 in) |
| 5. | ZC16X02000 | [4] | CLIP | KOBClamp, Hose -- Min 15 x Max 25mm |
| 6. | ZM73C10025 | [5] | BOLT,M10x25mm - Course Thread | KOBM10x1.50x25mm (Incls. Washer) |
| 7. | ZM73C06020 | [2] | BOLT,M6x20mm - Course Thread | KOBM06x1.0x20mm (Incls. Washer) |
| 8. | ZM73C08020 | [7] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| 9. | ZS18C08100 | [4] | SCREW,Hex, M8 x 100mm | KOBScrew -- M08x1.25x100mm |
| 10. | ZW16P08000 | [4] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| 12. | YJ21M01003D1 | [1] | FLEXIBLE HOSE | SMID 22.1 x OD 27 x 1800mm |
| 13. | YN20M01046D9 | [1] | TUBE,22.10mm ID x 27.00mm OD x 1700.00mm | KOBProtective Plastic |
| 14. | 2418Z1333D29 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1450mm Length | KOB |
| 15. | YN20M01094D6 | [1] | TUBE,25mm ID x 30mm OD x 1500mm Length | KOB |
| 16. | YY20M01142P1 | [1] | BRACKET | KOB |
| 17. | 2418Z1333D14 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1600mm Length | KOBProtective Plastic |
| 19. | 2418Z1333D6 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1400mm Length | KOB |
| 25. | PY01P01043D4 | [15] | CABLE TIE,4.80mm W x 251mm L | KOBWire Ties -- 249mm Long |
| 30. | YN20M01468P3 | [1] | PANEL | SM Superseded by part number: YN20M01468P4 |
| 32. | YX91V00001F1 | [1] | COMPRESSOR,W/ Pulley | KOBAssembly, Air |
| . . | YX91V00001F1R | [1] | REMAN-COMPRESSOR,W/ Pulley | KOBE70B BTW YT05-15001 - 18000 (NA) (4/08-) |
| . . | YX91V00001F1C | [1] | CORE-COMPRESSOR | KOBReturn Number |
| 33. | YN20M01696F1 | [1] | PULLEY,98mm OD | SMAssembly (Includes Tensioner Bolt) |
| 35. | YT96V00004F1 | [1] | EVAPORATOR | KOBDrier Assembly, Air |
| 40. | YN52S00044P1 | [1] | SENSOR | SMSunshine |
| 49. | YN13E01375P1 | [2] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 50. | 2444Z1630 | [2] | FITTING | KOB3/8 PT Hose |
| 51. | YT20M01157P1 | [1] | HYD CONNECTOR | KOB |
| 52. | YT20M01179P1 | [1] | HYD CONNECTOR | KOB |
| 53. | 2432R226D13 | [2] | CLIP | KOBClamp, Double -- ID 28 x 82mm Long |
| 58. | YT20M01161P1 | [1] | INSULATION | KOB |
| 59. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
