纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-67-00[01]) - AIR CONDITIONER ASSEMBLY (YN20M00107F3), PAGE 1 OF 2 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
321 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN20M00107F3 | [1] | AIR CONDITIONER | SMAIR CONDITIONING Assembly, Page 1 of 2 Superseded by part number: YT20M00022F4 |
| 1. | YN20M00107S001 | [23] | SCREW | KOBTapping |
| 2. | YN20M00107S002 | [1] | HARNESS | KOB Superseded by part number: YT20M00022S002 |
| 3. | YN20M00107S003 | [3] | ACTUATOR | KOB Superseded by part number: YT20M00022S113 |
| 31. | YN20M00107S031 | [9] | SCREW | KOBTapping |
| 36. | YN20M00107S036 | [1] | GUARD | SMDamper |
| 37. | YN20M00107S037 | [1] | GUARD | SMDamper |
| 38. | YN20M00107S038 | [1] | GUARD | SMDamper |
| 39. | YN20M00107S039 | [1] | GASKET | SMPacking |
| 40. | YN20M00107S040 | [1] | GASKET | SMPacking |
| 41. | YN20M00107S041 | [1] | LEVER | SM |
| 42. | YN20M00107S042 | [1] | LEVER | SM |
| 43. | YN20M00107S043 | [1] | LEVER | SM |
| 45. | YN20M00107S045 | [1] | LEVER | SM |
| 49. | YN20M00107S049 | [1] | ROD | SM |
| 50. | YN20M00107S050 | [1] | ROD | SM |
| 86. | YN20M00107S086 | [1] | BOX | SMCase |
| 87. | YN20M00107S087 | [1] | BOX | SMCase |
| 88. | YN20M00107S088 | [1] | LEVER | SM |
| 89. | YN20M00107S089 | [1] | LEVER | SM |
| 90. | YN20M00107S090 | [1] | LEVER | SM |
| 91. | YN20M00107S091 | [1] | ROD | SM |
| 92. | YN20M00107S092 | [1] | PLATE | SM |
