神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (05-003) - ROLLER ASSY P/N 24100N2301F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
608 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2301F2 | [1] | ROLLER ASSY, Serial Range: LE3401--LE3952 | |
| . . | 24100N2301F3 | [1] | ROLLER ASSY, Serial Range: LE3953--LE4666 | |
| . . | 24100N2301F4 | [1] | ROLLER ASSY, Start Serial: LE4667- | ROLLER ASSY, Start Serial: LE4667- |
| 1. | 2413NT27 | [1] | ROLLER,LOW, Serial Range: LE3401~-LE4666 | |
| 3. | 2418N1894D1 | [1] | COLLAR | COLLAR |
| 4. | 2418N1894D2 | [1] | COLLAR | COLLAR |
| 5. | 2418T3578 | [1] | RING LOCK | RING LOCK |
| 6. | R45P0018D6 | [2] | SEAL | KOB Superseded by part number: 2445R439F1 |
| 7. | ZD11G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOB |
| 8. | ZE82T04000 | [2] | PLUG | KOB1/4" PT |
| 9. | 2405T866 | [2] | BUSHING | KOB |
| 10. | 2419P1531 | [1] | SHAFT, Serial Range: LE3401--LE3952 | |
| 11. | 2419P153102 | [1] | SHAFT, Start Serial: LE3953- | |
| 12. | 2413N327C2 | [1] | ROLLER LOW, Start Serial: LE4667- | ROLLER LOW, Start Serial: LE4667- |
