神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (05-006) - SPRING ASSY, TRACK P/N 24100N2766F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
631 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2766F2 | [1] | TRACK ASSY | KOB |
| 2. | 2416N2282 | [1] | BRACKET | BRACKET |
| 3. | ZN21C24027 | [1] | NUT | KOB Superseded by part number: ZN23C24027 |
| 4. | ZP26D05036 | [1] | PIN | KOBSpring |
| 5. | 2417P178C2 | [1] | SPRING | SPRING |
| 6. | ZS13C12030 | [2] | CAPSCREW | KOBSCREW M12x1.75x30mm Superseded by part number: ZS18C12030 |
| 7. | 2444R663 | [1] | FITTING | KOBNIPPLE |
| 9. | 2439P160 | [1] | PISTON | KOBPISTON |
| 10. | 2418T7294 | [1] | PLATE | KOB |
| 11. | 2445Z1080 | [1] | DUST CAP | KOBSEAL, BUST |
| 12. | 2445Z1081 | [1] | SEAL | KOB |
| 14. | 2438N23702 | [1] | CYLINDER, GREASE | |
| 15. | ZM11C08016 | [1] | BOLT | KOBM08x1.25x16mm (Incls. Lockwasher) |
