纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-73-00[07]) - HARNESS ASSEMBLY, UPPER (YT13E00048F1), PAGE 7 OF 12 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
274 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10. | EW02E01015D9 | [8] | CLIP,20mm ID, P Type | KOBClamp -- Ø20x25mm Long |
| 12. | PY01P01043D4 | [1] | CABLE TIE,4.80mm W x 251mm L | KOBWire Ties -- 249mm Long |
| 13. | EW02E01015DD | [2] | CLIP | KOBClamp -- Ø40X36mm Long |
| 15. | PY01P01043D3 | [73] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 17. | YN13E01375P1 | [25] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 22. | ZM73C08016 | [13] | BOLT,M8x16mm - Course Thread | KOBM08x1.25x16mm (Incls. Washer) |
| 23. | ZM73C10020 | [12] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
| 30. | EW02E01016D8 | [1] | CLIP | KOBClamp, Single -- Ø18x21mm Long |
| 33. | ZN18C05004 | [1] | NUT | KOBM05x0.8mm |
| 35. | ZW16P05000 | [3] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 38. | ZW26X05000 | [2] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 39. | ZS16C05012 | [2] | CAPTIVE WASHER SCREW | KOBM05x0.8x12mm |
