纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-73-00[08]) - HARNESS ASSEMBLY, UPPER (YT13E00048F1), PAGE 8 OF 12 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
255 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10. | EW02E01015D9 | [8] | CLIP,20mm ID, P Type | KOBClamp -- Ø20x25mm Long |
| 13. | EW02E01015DD | [2] | CLIP | KOBClamp -- Ø40X36mm Long |
| 15. | PY01P01043D3 | [73] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 16. | PY01P01043D8 | [7] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| 17. | YN13E01375P1 | [25] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 22. | ZM73C08016 | [13] | BOLT,M8x16mm - Course Thread | KOBM08x1.25x16mm (Incls. Washer) |
| 23. | ZM73C10020 | [12] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
