纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-73-00[10]) - HARNESS ASSEMBLY, UPPER (YT13E00048F1), PAGE 10 OF 12 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
985 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | YT13E01142P1 | [1] | ELECTRIC CABLE | KOB |
| 4. | YT13E01143P1 | [1] | ELECTRIC CABLE | KOB |
| 5. | YT13E01144P2 | [1] | ELECTRIC CABLE | KOB |
| 15. | PY01P01043D3 | [73] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 17. | YN13E01375P1 | [25] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 22. | ZM73C08016 | [13] | BOLT,M8x16mm - Course Thread | KOBM08x1.25x16mm (Incls. Washer) |
