纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-73-00[12]) - HARNESS ASSEMBLY, UPPER (YT13E00048F1), PAGE 12 OF 12 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
930 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8. | YT13E01148P1 | [1] | BRACKET | KOBBracket |
| 15. | PY01P01043D3 | [73] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 16. | PY01P01043D8 | [7] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| 17. | YN13E01375P1 | [25] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 32. | ZM61C06016 | [1] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
