纽荷兰零件查询(E70BSR) - COMPACT CRAWLER EXCAVATOR BTW YT05-15001 - 18000 (NA) (4/08-) (02-74-00[00]) - HARNESS ASSEMBLY, CAB (YT14E00029F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
885 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT14E01078P2 | [1] | HARNESS | KOB Superseded by part number: YT14E01078P4 |
| 2. | YN13E01375P1 | [13] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 3. | ZM73C06016 | [1] | BOLT,M6x16mm - Course Thread | KOBM06x1.0x16mm (Incls. Washer) |
| 4. | PY01P01043D3 | [19] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 6. | YN14E01106P1 | [1] | HARNESS | KOB |
