神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (09-006) - BUCKET ASSY, 0.25M³ Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
271 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2410002247F1 | [1] | BUCKET ASSY LE 3401 to LE 5489 | |
| . . | 2 4100N2247F2 | [1] | BUCKET ASSY LE, Start Serial: 5490 | |
| 1. | 2412J329F1 | [1] | BUCKET LE 3401 to LE 5489 | |
| 1-1. | 2412J329 | [1] | | |
| 1-1O. | 2412P314D2 | [1] | EDGE, CUTTING | EDGE, CUTTING |
| 1-1P. | 2412N214 | [4] | ADAPTER | KOB |
| 1-18. | 2405T873 | [4] | BUSHING | KOB |
| 2. | B12P0015F1 | [4] | TOOTH | KOB |
| 2-1. | B12P0015E1 | [1] | BUCKET TOOTH POINT | KOB |
| 2-2. | B12P0015E2 | [1] | PIN | KOB Superseded by part number: 2412Z162K |
| 2-3. | B12P0015E3 | [1] | LOCK PIN | KOB Superseded by part number: B12P0015E3MK |
| 5. | R16T0152D3 | [6] | WASHER | KOB |
| 7. | ZN13F20016 | [6] | NUT | KOBM20x1.50mm |
| 8. | 2445Z912 | [4] | O-RING | KOBID 90 ± 0.40 x OD 108mm |
| 9. | 2412N279D1 | [1] | BLADE | KOB |
| 10. | 2412N279D2 | [1] | BLADE | KOB |
| 11. | ZS13F20055 | [6] | SCREW | KOBM20x1.50x55mm |
| 12. | 2412J660F1 | [1] | BUCKET LE, Start Serial: 5490 | |
| 12-1. | 2412J660F1 | [1] | BUCKET | |
| 12-1O. | 2412P314D2 | [1] | EDGE, CUTTING | EDGE, CUTTING |
| 12-1P. | 2412N214 | [4] | ADAPTER | KOB |
| 12-18. | 2405T873 | [4] | BUSHING | KOB |
