纽荷兰零件查询(E80) - MIDI CRAWLER EXCAVATOR ASN LF04-02001 (03-003) - HYDRAULIC LINES, BOOM 3.72M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
389 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 01. | LF01V00005F1 | [1] | CYLINDER | KOBASSY, BOOM |
| 02. | YT01V00002F1 | [1] | CYLINDER ASSY. | KOBARM |
| . . | LF42H00004F1 | [1] | HYD LINES, BOOM | |
| A1. | LF42H01012P1 | [2] | TUBE | KOB |
| A2. | LF42H01021P1 | [1] | TUBE | KOB |
| A3. | LF42H01022P1 | [1] | TUBE | KOB |
| A4. | LF42H01040P1 | [1] | TUBE | KOB |
| A5. | LF42H01041P1 | [1] | TUBE | KOB |
| A6. | LF42H01023P1 | [2] | TUBE | KOB |
| A7. | ZA23B22000 | [2] | HYD CONNECTOR | KOB |
| A8. | ZE72X12000 | [2] | PLUG | KOB |
| A9. | ZC26X22011 | [10] | CLAMP | KOB |
| A10. | ZC36X22011 | [6] | CLAMP | KOB |
| A11. | LF42H01017P1 | [2] | CLAMP | KOB |
| A12. | ZS18C10045 | [16] | SCREW,Hex, M10 x 45mm | KOBCAP |
| A13. | ZS18C10055 | [4] | SCREW,Hex, M10 x 55mm | KOBCAP |
| A14. | ZW26X10000 | [20] | LOCK WASHER | KOB |
| . . | LF42H00006F2 | [1] | HYD LINES, CYLINDER | |
| B2. | LF42H01033P1 | [1] | TUBE | KOB |
| B3. | ZA23F22008 | [1] | HYD CONNECTOR | KOB |
| B4. | ZA33F22008 | [1] | ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB |
| B5. | ZD12P01800 | [2] | O-RING | KOB |
| B6. | YR43H01003P1 | [2] | CLAMP | KOB |
| B7. | ZS18C10050 | [2] | SCREW,Hex, M10 x 50mm | KOBCAP |
| B9. | ZG91V02000 | [1] | LUBE NIPPLE | KOB |
| B10. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
| B11. | ZE72X04000 | [1] | PLUG | KOB |
| B12. | YT42H01241P1 | [1] | TUBE | KOB |
| . . | YT42H00003F1 | [1] | HYD LINES, CYLINDER | |
| C1. | YT42H01009P1 | [1] | TUBE | KOB |
| C2. | YT42H01030D1 | [2] | HOSE | KOB |
| C4. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB |
| C6. | ZG91U02000 | [1] | LUBE NIPPLE | KOB |
