神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (09-013) - BUCKET ASSY, EJECTOR P/N 24100X1270F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
859 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X1270F1 | [1] | BUCKET ASSY, HOE | |
| 1. | 24100P920F1 | [1] | BUCKET ASSY | |
| 1-1. | 2412J339F1 | [1] | EDGE, CUTTTING | |
| 1-1B. | 2412T231 | [1] | ADAPTER | |
| 1-1N. | 2412N214 | [2] | ADAPTER | KOB |
| 1-1R. | 2405T873 | [4] | BUSHING | KOB |
| 1-2. | B12P0015F1 | [2] | TOOTH | KOB |
| 1-2A. | B12P0015E1 | [1] | BUCKET TOOTH POINT | KOB |
| 1-2B. | B12P0015E2 | [1] | PIN | KOB Superseded by part number: 2412Z162K |
| 1-2C. | B12P0015E3 | [1] | LOCK PIN | KOB Superseded by part number: B12P0015E3MK |
| 2. | 2412J340F1 | [1] | EJECTOR | |
| 2-13. | NSS | [2] | NOT SOLD SEPARAT | CON |
| 2-14. | NSS | [2] | NOT SOLD SEPARAT | CON |
| 3. | 2406N389 | [1] | LINK, EJECTOR | |
| 4. | 2406N684F1 | [1] | LINK, BUCKET | |
| 4-10. | NSS | [2] | NOT SOLD SEPARAT | CONBUSHING |
| 4-11. | NSS | [2] | NOT SOLD SEPARAT | CONBUSHING |
| 4-12. | NSS | [2] | NOT SOLD SEPARAT | CONBUSHING |
| 5. | 2419P1483 | [1] | PIN (15) | |
| 6. | 2419P760F2 | [2] | PIN (16) | |
| 7. | 2420T2446 | [2] | CAPSCREW | |
| 8. | NSS | [2] | NOT SOLD SEPARAT | CONNUT |
| 9. | NSS | [2] | NOT SOLD SEPARAT | CONSPLIT PIN |
| 10. | NSS | [2] | NOT SOLD SEPARAT | CONSETSCREW |
| 11. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 12. | 2445Z912 | [4] | O-RING | KOBID 90 ± 0.40 x OD 108mm |
| 13. | 2445R138D1 | [6] | SEAL,50mm ID x 65mm OD x 4mm Thk | KOBDust -- ID 50 x OD 65 x Th 4mm |
| 14. | 2445R138D5 | [2] | SEAL,40mm ID x 50mm OD x 4mm Thk | KOBDust -- ID 40 x OD 50 x Th 4mm |
| 15. | 2419P1589 | [1] | PIN | PIN |
| 16. | 2419P1590F1 | [2] | PIN | |
| 16-1. | 2419P1590 | [1] | PIN | |
| 16-2. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
