| . . | 24100N2374F1 | [1] | ARM ASSY | |
| 1. | 2411N1417F1 | [1] | ARM | |
| 1-24. | 2405P258 | [2] | BUSHING | KOB |
| 1-25. | 2405T594C2 | [2] | BUSHING | KOB |
| 1-26. | 2405T595C2 | [2] | BUSHING | KOB |
| 1-27. | 2418T10049 | [1] | SPACER (29), Serial Range: LE3401--LE4774 | SPACER (29), Serial Range: LE3401--LE4774 |
| 1-28. | 2418T10048 | [1] | BUSHING | KOBSPACER (30), Serial Range: LE3401--LE4774 Superseded by part number: 2418T10843 |
| 1-29. | 22418T10842 | [1] | SPACER (27), Start Serial: LE4775- | |
| 1-30. | 2418T10843 | [1] | SPACER | KOB(28), Start Serial: LE4775- |
| 2. | 2438U700F1 | [1] | CYLINDER | |
| 3. | 2406P2299D1F1 | [1] | LINK | KOB |
| 3-5. | 2405T596C2 | [2] | BUSHING | KOB |
| 4. | 2406P2299D2F1 | [1] | LINK | KOB |
| 4-5. | NSS | [2] | NOT SOLD SEPARAT | CON |
| 5. | 2406P2461D1 | [1] | LINK, IDLER | |
| 6. | 2406P2461D2 | [1] | LINK, IDLER | |
| 7. | 2419P1565D2 | [2] | PIN (36), Serial Range: LE3401--LE4236 | PIN (36), Serial Range: LE3401--LE4236 |
| 8. | 2419P1565D1 | [1] | PIN | KOB |
| 9. | 2419P1553 | [1] | PIN | PIN |
| 10. | 2419T3364 | [1] | PIN | |
| 11. | 2418P8328 | [1] | TUBE | TUBE |
| 12. | 2418P8329 | [1] | TUBE | |
| 13. | 2416T3204 | [2] | CLAMP | KOB |
| 14. | 2445R138D1 | [6] | SEAL,50mm ID x 65mm OD x 4mm Thk | KOBDust -- ID 50 x OD 65 x Th 4mm |
| 15. | 2445R138D3 | [2] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| 16. | 2445R220D5 | [4] | SEAL,50mm ID x 65mm OD x 5mm Thk | KOBDust -- ID 50 x OD 65 x Th 5mm Superseded by part number: 71436184 |
| 17. | ZX57N08120 | [2] | HOSE | KOB |
| 18. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 19. | ZG91U02000 | [2] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 20. | ZK23E18008 | [2] | HYD CONNECTOR | KOB Superseded by part number: ZF23E18008 |
| 21. | 2416T8738 | [1] | SPACER | KOB |
| 22. | 2411T661 | [1] | COVER, SLIDE | |
| 23. | 2406P2462F1 | [1] | GUIDE | |
| 23-5. | 2405T948 | [2] | BUSHING | |
| 24. | 2416T9886 | [1] | SUPPORT | |
| 25. | 7418T10012 | [1] | SPACER | |
| 26. | 2419T3365 | [2] | PIN | |
| 27. | 2416T9887 | [1] | SUPPORT | |
| 28. | ZS16C08030 | [4] | CAPSCREW M08x1.25x30mm | CAPSCREW M08x1.25x30mm |
| 29. | ZS18C08020 | [4] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 30. | ZS13C16035 | [5] | SCREW | KOBM16x2.0x35mm |
| 31. | ZS13C12110 | [6] | SCREW | KOBM12x1.75x110mm Superseded by part number: ZS18C12110 |
| 32. | 2419P1530 | [1] | PIN (37), Serial Range: LE3401--LE4534 | |
| 33. | ZN17C12010 | [12] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 34. | ZW26X08000 | [8] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 35. | ZW22X16000 | [5] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 36. | 2419P1617D1 | [2] | PIN (38), Serial Range: LE4237--LE4534 | PIN (38), Serial Range: LE4237--LE4534 |
| 37. | 2419P1631 | [1] | PIN, Start Serial: LE4535- | PIN, Start Serial: LE4535- |
| 38. | 2419P1607D1 | [2] | PIN | KOB, Start Serial: LE4535- |
