神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (11-001) - INSTAL HYDR LINES, BOOM 3.65M (NIBBLER & BREAKER) P/N 24100J4800F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
417 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J4800F1 | [1] | INSTAL,HYDR LINES | |
| 1. | 2418T10133 | [1] | TUBE | |
| 2. | 2418T10134 | [1] | TUBE | |
| 3. | 2418T10135 | [1] | TUBE | |
| 4. | 2418T10136 | [1] | TUBE | |
| 5. | ZK23B22000 | [1] | HYD CONNECTOR | KOB Superseded by part number: ZA23B22000 |
| 6. | ZK23B18000 | [1] | HYD CONNECTOR | KOB |
| 7. | 2416T98D4 | [5] | PLATE | |
| 8. | 2416T9899 | [5] | BLOCK | KOBBLOCK, TAPPED |
| 9. | ZC26X22011 | [5] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 10. | ZC26X18011 | [5] | CLAMP | KOB Superseded by part number: ZC26M18011 |
| 11. | ZS16C10045 | [5] | SCREW | KOBM10x1.50x45mm Superseded by part number: ZS18C10045 |
| 12. | ZS16C10040 | [5] | SCREW | KOBM10x1.50x40mm Superseded by part number: ZS18C10040 |
| 13. | ZW26X10000 | [10] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 14. | 2444R868D1 | [1] | HOSE | |
| 15. | ZX27N08060 | [1] | HOSE | KOB |
