神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (11-007) - CONTROL ASSY (SIDE DIGGING) P/N 24100J4822F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
705 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J4822F2 | [1] | CONTROL ASSY, Serial Range: LE3401-LE4161 | |
| . . | 24100J4822F5 | [1] | CONTROL ASSY, Start Serial: LE4162 | |
| 1. | 2410N2408F1 | [1] | PEDAL ASSY | |
| 1-1. | 2406PJ467F1 | [1] | PEDAL | |
| 1-1E. | 2405T975 | [2] | BUSHING | |
| 1-2. | 2416P7165 | [1] | BRACKET | |
| 1-3. | 2419T3412 | [1] | PIN | |
| 1-4. | NSS | [1] | NOT SOLD SEPARAT | CONSPLIT PIN |
| 1-5. | ZS16C12060 | [1] | CAPSCREW M12x1.75x60mm | CAPSCREW M12x1.75x60mm |
| 1-6. | ZS16C12040 | [1] | SCREW | KOBM12x1.75x40mm Superseded by part number: ZS18C12040, 77276427 |
| 1-7. | ZN16C12010 | [2] | NUT | KOB Superseded by part number: ZN18C12010 |
| 2. | ZS13C10025 | [4] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 3. | ZW22X10000 | [5] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 4. | ZN17C10008 | [4] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 5. | ZP45X12030 | [1] | PIN | KOB, Serial Range: LE3401-LE4102 |
| . . | 2419T3642D1 | [1] | PIN | KOB, Serial Range: LE4103-LE5080 Superseded by part number: 2419T3784D1 |
| 6. | ZW16X12000 | [1] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 7. | 2419R9D4 | [1] | COTTER PIN | KOBSnap -- OD 12mm x 35.8mm Long |
| 8. | 2406T1385 | [1] | YOKE | KOB, Serial Range: LE3401-LE4102 Superseded by part number: 2406T2278 |
| . . | 2406T1672 | [1] | YOKE | KOB, Start Serial: LE4103 Superseded by part number: 2406T2278 |
| 9. | 2406R219D1 | [1] | FLEXIBLE CONTROL | KOB |
| 10. | ZN16C08007 | [2] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 12. | 2420T4065 | [1] | STUD | KOB |
| 13. | 2420Z681 | [1] | ROD | KOB |
| 14. | ZN16C08007 | [1] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 20. | 2427D1791 | [1] | MAT, FLOOR, Serial Range: LE3401-LE4161 | |
| 25. | ZK23F18008 | [2] | HYD CONNECTOR | KOB |
| 26. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 28. | 2418T10192D1 | [2] | TUBE | |
| 30. | 2418P8437 | [1] | TUBE | |
| 31. | 2432T1712 | [1] | CLAMP | |
| 32. | ZS13C10385 | [1] | CAPSCREW | |
| 33. | 2418P8456 | [1] | TUBE | |
| 34. | 2436R558F1 | [1] | VALVE KIT CONTROL | |
| 35. | ZK33B1800 | [2] | ELBOW | |
| 37. | 2422J1322 | [1] | FRAME UPP | |
| 37-1. | 2416T12933 | [1] | BRACKET | |
| 41. | 2427Z525 | [1] | MAT, FLOOR, Start Serial: LE4162 | |
| 45. | 2419T3784D1 | [1] | PIN | KOB, Start Serial: LE5081 |
