凯斯零件查询(LB424R) - BALER (9/12-) (90.105.050) - TWINE BOXES LH SUPPORT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
786 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84394922
|
[1] |
MOUNTING PLATE
|
ZED
|
| 2. |
336455
|
[2] |
PLUG
|
ZED
, Serial Range: -C055
|
| 2. |
331233
|
[2] |
PLUG
|
ZED
, Start Serial: D056
|
| 3. |
84421934
|
[4] |
LEAF SPRING
|
ZED
|
| 4. |
84275921
|
[6] |
GUIDE
|
ZED
|
| 5. |
84444540
|
[4] |
WASHER,35mm ID x 45mm OD x 2mm Thk
|
ZED
|
| 6. |
84819384
|
[2] |
COVER
|
ZED
|
| 7. |
84421624
|
[1] |
SHIELD
|
ZED
|
| 8. |
370004
|
[6] |
SNAP RING,M35 x 1.5mm Thk, External
|
NH
Superseded by part number: 11068376
|
| 9. |
86619060
|
[6] |
CARRIAGE BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
|
| 10. |
378243
|
[6] |
WASHER,8.4mm ID x 21mm OD x 1.6mm Thk
|
NH
Superseded by part number: 63707, 63707, 86625263
|
| 11. |
322358
|
[7] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 12. |
9706690
|
[7] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 13. |
140017
|
[6] |
WASHER,M10 x 20mm OD x 2mm Thk
|
PA
, Serial Range: -C091 Superseded by part number: 9820489
|
| 13. |
86624176
|
[6] |
WASHER,11mm ID x 20mm OD x 2mm Thk
|
FOR
, Start Serial: D092 Superseded by part number: 14496621
|
| 14. |
120041
|
[4] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 15. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 16. |
100016
|
[6] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 17. |
120103
|
[1] |
BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
Superseded by part number: 16043224
|
