神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (01-016) - COVER ASSY, UNDER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
264 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2992F2 | [1] | COVER,UNDER | |
| 1. | 2414T2699 | [1] | COVER | |
| 7. | ZS18C12030 | [22] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 8. | 2418T10357 | [22] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| 9. | 2414T2785F1 | [1] | COVER ASSY | |
| 9-1. | 2414T2753 | [1] | COVER | |
| 9-2. | 2479T1149 | [1] | INSULATION,SOUND | |
| 10. | 2414T2786F1 | [1] | COVER ASSY,LE5701-5893 | |
| . . | 2414T2800F1 | [1] | COVES ASSY,LE5894- | |
| 10-1. | 2414T2752 | [1] | COVER,LE5701-5893 | |
| . . | 2414T2801 | [1] | COVER,LE5894- | |
| 10-2. | 2479T1150 | [1] | INSULATION,SOUND | |
| 11. | ZW26X12000 | [22] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 12. | 2414T2792 | [1] | COVER | COVER |
| 13. | 2414T2793 | [1] | COVER | COVER |
| 14. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 15. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
