神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (09-003[01]) - LABEL, NAME-PLATE, 24100J6447F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
402 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6447F1 | [1] | LABEL,NAME-PLATE | |
| 1. | 2432T2308 | [1] | LABEL | KOB |
| 2. | 2432T2309 | [1] | LABEL | KOB |
| 3. | 2432T2360 | [1] | LABEL | LABEL |
| 4. | 2432J1315 | [2] | TYPE PLATE | KOB |
| 5. | 2432N1100 | [1] | TYPE PLATE | KOB |
| 6. | 2432T2304D7 | [1] | LABEL | KOB |
| 7. | 2432T2361 | [1] | LABEL | LABEL |
| 8. | 2432T2359 | [1] | LABEL | KOB |
| 9. | 2432T2358 | [1] | LABEL | LABEL |
| 10. | 2432T2312 | [1] | LABEL | KOB |
| 11. | 2432T2306D2 | [1] | LABEL | LABEL |
| 12. | 2432T2310 | [1] | LABEL | LABEL |
| 13. | 2432T2311 | [1] | LABEL | LABEL |
| 14. | 2432T2394 | [1] | TYPE PLATE | KOB |
| 15. | 2432T2393 | [1] | TYPE PLATE | KOB |
| 16. | 2432T1142D3 | [2] | LABEL | KOB |
| 17. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 18. | 2432T1530 | [1] | IDENTITY PLATE | KOB |
| 19. | 2427Z329 | [3] | SHEET | KOBAnti-Slip (300x150mm) |
| 20. | 2432T884 | [1] | LABEL | KOB |
| 21. | 2432T892 | [1] | LABEL | KOB |
| 22. | 2432T2283 | [1] | LABEL | KOBDecal, Fuel location |
| 23. | 2432J1316 | [1] | LABEL | KOB |
| 24. | 2432T1759 | [1] | PLATE | KOB |
| 25. | 2432T1753 | [1] | LABEL | KOBDecal, Kobelco Operation Superseded by part number: YN20T01407P1 |
| 25. | 2432N568 | [1] | INSTALLER JIG | KOB Superseded by part number: 2432N1751 |
| 27. | 2432N578 | [1] | PLATE | KOB |
| 28. | 2432T2991D1 | [1] | LABEL | KOB |
| 29. | 2432N1097 | [1] | LABEL | KOBDecal, Danger - Stay out of the swing area. |
| 30. | 2432T2316 | [1] | LABEL | KOB |
| 32. | 2432T2341 | [1] | LABEL | KOB |
| 33. | 2432P1014 | [1] | LABEL | KOB |
| 34. | 2446U228S12 | [1] | LABEL | KOB |
