神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (04-016) - HEATER ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
517 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N3038F1 | [1] | HEATER ASSY | |
| 1. | 2479U293D2 | [1] | HEATER | KOB |
| 2. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 3. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 4. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 6. | R18T0026D7 | [2] | HOSE,12mm ID x 2300mm L | KOB |
| 7. | R16T0238D1 | [2] | CLIP | KOB |
| 8. | 2444Z1633 | [1] | COCK | KOB Superseded by part number: PH21M01008P1 |
| 9. | 2444T2527 | [1] | HYD CONNECTOR | KOB |
| 10. | 2444Z1630 | [1] | FITTING | KOBConnector -- 3/8" PT Hose |
| 11. | 2432Z290 | [5] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 12. | 2414Z199D25 | [1] | PROTECTIVE SLEEVE | KOB Superseded by part number: 2414Z199D025 |
| 13. | ZC15X02300 | [2] | CLIP | KOB |
