神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (05-001) - INSTAL, LOW Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
419 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6216F2 | [1] | INSTAL LOW | |
| 2. | 2425U235F1 | [1] | RING | KOBBEARING, P.487-01, Serial Range: LE5701-LE-5703 Superseded by part number: 2425U261F1 |
| 2. | 2425U235F2 | [1] | RING | KOBBEARING, P.487-01, Start Serial: LE5704 Superseded by part number: 2425U261F1 |
| 3. | 2441U532F1 | [2] | HYDRAULIC MOTOR | KOB |
| 4. | 24100N2970F1 | [2] | IDLER WHEEL | KOBP.451-01 |
| 6. | 24100N2973F1 | [2] | TRACK ASSY | KOB |
| 7. | 2422T556 | [1] | PLATE | KOB90x50x Th 06mm |
| 8. | 2418T12274 | [1] | PACKING | KOB90x50x Th 05mm -- Rubber |
| 9. | 24100N2969F1 | [10] | TRACK ROLLER | KOBP.461-01 |
| 10. | 24100N2165F2 | [2] | TRACK ROLLER | KOBP.467-01 |
| 12. | ZS13C16040 | [24] | SCREW | KOBM16x2.0x40mm |
| 13. | ZS13C14030 | [24] | SCREW | KOBM14x2.0x30mm Superseded by part number: ZS18C14030 |
| 14. | ZS13C16090 | [30] | CAPSCREW | KOBSCREW M16x2.0x90mm |
| 15. | ZS13C14055 | [40] | SCREW | KOBM14x2.0x55mm Superseded by part number: ZS18C14055 |
| 15. | ZS13C16075 | [2] | SCREW | KOBM16x2.0x75mm |
| 17. | ZS23C08020 | [3] | SCREW,Hex Socket Head, M8 x 20mm | KOBM08x1.25x20mm |
| 18. | ZS13C16110 | [1] | SCREW | KOBM16x2.0x110mm |
| 19. | ZN13C16013 | [3] | NUT | KOBM16x2.0mm |
| 20. | ZW22K08000 | [3] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 21. | ZS13C12025 | [8] | SCREW | KOBM12x1.75x25mm Superseded by part number: ZS18C12025 |
| 22. | ZS13C10014 | [2] | SCREW | KOBM10x1.50x14mm Superseded by part number: ZS18C10014 |
| 23. | ZW11X12000 | [8] | WASHER | KOBID 12 x OD 24 x Th 2.3mm Superseded by part number: ZW16X12000 |
| 24. | ZW22K12000 | [8] | LOCK WASHER | KOBID 12.2 x OD 17.8 x Th 2.5mm |
| 25. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 26. | 2414N1933 | [2] | COVER | KOB |
| 27. | 2422U1720 | [1] | FRAME,LOW | |
| 28. | 2436U881F2 | [1] | JOINT, SWIVEL | JOINT, SWIVEL |
| 29. | 2404N250 | [2] | DRIVING SPROCKET | KOB |
| 30. | 2418T17441D1 | [40] | WASHER | KOB |
