神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (05-002) - IDLER ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
540 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2970F1 | [1] | IDLER WHEEL | KOB |
| 1. | 2413N386 | [1] | IDLER | IDLER |
| 2. | ZE82T02000 | [2] | PLUG | KOBPipe, 1.25" PT |
| 3. | 2445Z1112 | [2] | SEAL | KOB Superseded by part number: ZD58F07629 |
| 4. | 2419T2668D3 | [2] | PIN | KOB Superseded by part number: 2419T6402 |
| 5. | 2444N215 | [2] | SLIDE VALVE | KOB |
| 6. | 2410P766 | [1] | ROLLER SHAFT | KOB |
| 7. | ZD11G04500 | [2] | O-RING,44.40mm ID x 50.60mm OD x 3.10mm | KOBID 44.40 ± 0.41 x OD 50mm |
| 8. | 2405P479 | [2] | BUSHING | KOB |
