神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (07-002) - REWORK, GUARD ASSY (OVER LOAD ALARM) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
607 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1650F1 | [1] | REWORK,GUARD | |
| 1. | 24100J6140F2 | [1] | GUARD ASSY,P.081-01 | |
| 2. | 2414N1986F1 | [1] | COVER,BATTERY | |
| 2-1. | 2421J164 | [1] | BOX | |
| 2-2. | 2414P4077 | [1] | COVER | |
| 2-2D. | 2427R476F1 | [1] | LOCK | KOB Superseded by part number: 2421R175F2 |
| 2-3. | 2414P4078 | [1] | COVER | |
| 2-4. | 2416Z454D5 | [1] | RUBBER,CUSHION | |
| 2-5. | 2416Z454D6 | [1] | RUBBER,CUSHION | |
| 2-6. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 2-7. | ZN13C12010 | [4] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 2-8. | ZN13C08007 | [2] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 2-9. | ZW16X12000 | [4] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 2-10. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 2-11. | ZW26X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 2-12. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 2-13. | 2419R9D3 | [1] | PIN | KOBHair -- OD 10mm x 32.6mm Long |
| 2-14. | ZW11X10000 | [1] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
