神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (07-003) - CONTROL ASSY (EXTRA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
417 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4051F1 | [1] | CONTROL ASSY | |
| 1. | 2406P2616 | [1] | PEDAL | KOB |
| 2. | 2408P504F1 | [1] | HOOK ASSY | HOOK ASSY |
| 2-1. | 2406T2355D1 | [1] | BAR | |
| 2-2. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 2-3. | ZP16K02516 | [2] | COTTER PIN | KOB Superseded by part number: ZP16K02520 |
| 2-4. | 2417T514 | [1] | SPRING | SPRING |
| 2-5. | 2416P8715 | [1] | BRACKET | |
| 3. | 2436U1142F1 | [1] | PILOT VALVE | KOB |
| 4. | ZH32X04000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 5. | 2444Z2336 | [1] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 6. | 2444T2501D1 | [1] | TEE | KOB |
| 7. | 2444Z2294 | [1] | HYD CONNECTOR | KOB1/4" PF x 41mm Long (Incls. (2) O-Rings ZD12P01100) |
| 8. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 9. | ZH21X08004 | [1] | CONNECTOR | |
| 10. | 2420R349D130 | [1] | FLEXIBLE HOSE | KOB1/4" PF, 1300mm Long (51-3/16 in) |
| 11. | 2420R349D180 | [1] | HOSE,6.35mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 12. | 2420R349D6 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 2420R349D050 |
| 13. | ZX15K08040 | [1] | PLASTIC-RUBBER TUBE | KOB |
| 14. | ZS23C10016 | [1] | SCREW,Hex Socket Head, M10 x 16mm | KOBM10x1.50x16mm Superseded by part number: ZS28C10016 |
| 15. | ZS13C08025 | [2] | SCREW | KOBM08x1.25x25mm Superseded by part number: ZS18C08025, 77276313 |
| 16. | ZW22K10000 | [1] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 17. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
