神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (07-005) - REWORK, HYDR LINES, P/N 24100N4059F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
771 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4059F1 | [1] | REWORK,HYDR LINES | |
| 1. | 2420R349D190 | [1] | HOSE,6.35mm ID x 1900mm L | KOB1900mm Long (74-13/16 in) |
| 2. | 2420R349D22 | [1] | HOSE ASSY | HOSE ASSY |
| 3. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 4. | 2418T17899 | [1] | TUBE | |
| 5. | 2418T17944 | [1] | TUBE | |
| 6. | ZH21M08004 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 7. | ZH51K08000 | [1] | TEE | KOB |
| 8. | ZX15K08060 | [1] | TUBE | KOB |
| 11. | ZC26X15009 | [2] | CLAMP | KOB |
| 12. | ZS13C08035 | [2] | SCREW | KOBM08x1.25x35mm Superseded by part number: ZS18C08035 |
| 13. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
