神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (07-004) - HYDR LINES, BRAKE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
464 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4050F1 | [1] | HYDR LINES, BRAKE PARKING | |
| 1. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 2. | ZH32X04000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 3. | ZH31M08006 | [2] | ELBOW | KOB |
| 5. | 2420R349D15 | [1] | HOSE | KOB Superseded by part number: 2420R349D090 |
| 6. | ZX15K08007 | [1] | TUBE,NYLON | |
| 7. | 2479Z85S | [1] | SWITCH | |
| 8. | 2479Z851 | [1] | HARNESS | |
| 9. | 2479Z979 | [1] | HARNESS | |
| 10. | 2415U158F5 | [1] | BRAKE,PARKING | |
| 11. | ZA23H18008 | [1] | HYD CONNECTOR | KOB |
| 12. | ZA33B18000 | [1] | ELBOW | KOBELBOW |
| 13. | 2418T17646 | [1] | TUBE | |
| 14. | 2418T17647 | [1] | TUBE | |
| 15. | 2418T17645 | [1] | TUBE | |
| 16. | 2418T5628 | [1] | SPACER | KOB |
| 17. | 2479Z1058 | [1] | HARNESS | |
