神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (07-012) - LIGHT ASSY, BACK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
529 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1117F2 | [1] | LIGHT ASSY, BACK | |
| 1. | 2456R229F2 | [1] | LIGHT HEAD,P.424-01 | LIGHT HEAD,P.424-01 |
| 2. | 2418T17375 | [1] | PLATE | |
| 3. | ZS18C12030 | [1] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 4. | 2432Z290D3 | [5] | CLIP | KOBWire Ties -- 154mm Long Superseded by part number: PY01P01043D3 |
| 5. | 2479Z849 | [1] | SWITCH | KOB Superseded by part number: 2479Z514 |
| 7. | 2479Z851 | [1] | HARNESS | |
| 8. | 2432Z309D2 | [2] | CLAMP | KOB |
| 9. | 2479Z869D5 | [1] | HARNESS | |
