神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (07-011) - REWORK, POWER-PLANT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
969 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1661F1 | [1] | REWORK,POWER-PLANT | |
| 1. | 2446U244F1 | [1] | CLEANER,AIR, Serial Range: LE5701-LE5856 | |
| . . | 2446U244F2 | [1] | CLEANER,AIR, Start Serial: LE5857 | |
| 1-1. | 2446U240S1 | [1] | BODY ASSY | |
| 1-2. | 2446U244S1 | [1] | ELEMENT | KOB(INNER) Superseded by part number: 87035489 |
| 1-3. | 2446U240S2 | [1] | ELEMENT ASSY (OUTER) | ELEMENT ASSY (OUTER) |
| 1-4. | 2446U226S4 | [2] | WING NUT | KOB |
| 1-5. | 2446U196S4 | [1] | COVER | KOB |
| 1-6. | 2446U240S5 | [1] | CAP | KOB |
| 1-7. | 2446U196S6 | [1] | CLAMP | KOBASSY |
| 1-8. | 2446U196S7 | [1] | CAP | KOB |
| 1-9. | 2446U240S9 | [1] | CAP, Start Serial: LE5857 | CAP, Start Serial: LE5857 |
| 1-10. | 2446U196S8 | [1] | VALVE | KOB, Start Serial: LE5857 |
