凯斯零件查询(LB424S) - BALER (9/12-) (88.060.030[02]) - SERVICE KIT: PACKER CRANKSHAFT & DRIVE KIT - C159 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
267 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
48095695
|
[1] |
Incl 2 - 21
|
SERVICE KIT
|
| 2. |
47624035
|
[1] |
CRANKSHAFT
|
ZED
|
| 3. |
9839342
|
[2] |
SET
|
ZED
|
| 4. |
385424
|
[1] |
BALL BEARING,45 mm ID x 85 mm OD x 56.3 mm
|
ZED
|
| 5. |
120044
|
[8] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 6. |
140046
|
[20] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 7. |
9706685
|
[32] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 8. |
853175
|
[2] |
FLANGE
|
ZED
Superseded by part number: 76450
|
| 9. |
722003
|
[1] |
BALL BEARING,55mm ID x 100mm OD x 25mm W
|
ZED
Superseded by part number: 47577177
|
| 10. |
84801730
|
[6] |
HALF-BUSHING
|
ZED
|
| 11. |
47845908
|
[3] |
CONNECTING ROD
|
ZED
|
| 12. |
47911884
|
[1] |
SPACER
|
ZED
|
| 13. |
84024519
|
[2] |
SHIM,55mm ID x 68mm OD x 1mm Thk
|
PLO
|
| 14. |
9850689
|
[3] |
SHIM
|
ZED
|
| 15. |
9839323
|
[6] |
SHIM
|
ZED
|
| 16. |
9839322
|
[6] |
SHIM
|
ZED
|
| 17. |
84801731
|
[3] |
SHIM
|
ZED
|
| 18. |
120093
|
[6] |
BOLT,M16 x 2.0 x 90.18mm, Cl 8.8
|
NH
|
| 19. |
412066
|
[6] |
NUT,M16 x 2.0, Cl 8
|
ZED
|
| 20. |
354298
|
[12] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 110mm, Cl 8.8, Full Thd
|
ZED
|
| 21. |
394631
|
[6] |
WASHER,17mm ID x 34mm OD x 4mm Thk
|
NH
|
