神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (01-022[04]) - STARTER (HITACHI) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
527 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8944234520 | [1] | STARTER MOTOR | KOBSTARTER ASM. |
| 1. | VI8941529670 | [1] | ARMATURE | KOBASM. Superseded by part number: VI8943654770 |
| 2. | VI8942284360 | [1] | BEARING | KOBBALL |
| 3. | VI8941529680 | [1] | BEARING | KOBBALL |
| 4. | VI8941529690 | [1] | COIL | KOBCOIL ASM., FIELD |
| 5. | VI8942284390 | [4] | SCREW, SET, POLE CORE | |
| 6. | VI8941529700 | [2] | BRUSH | KOB(+) |
| 7. | VI8941529710 | [1] | HOLDER, INJECTOR NOZ | KOBHOLDER ASM., BRUSH |
| 8. | VI8941529720 | [4] | SPRING, BRUSH | |
| 9. | VI8941529730 | [2] | BRUSH HOLDER | KOBBRUSH, (-) Superseded by part number: VI8941529700 |
| 10. | VI8941529740 | [1] | COVER, REAR | |
| 11. | VI8944503860 | [1] | CLUTCH ASM., PINION | |
| 12. | VI8944503870 | [1] | SHAFT, PINION | |
| 13. | VI8941529770 | [1] | CLUTCH ASM. | |
| 14. | VI8942284680 | [2] | BEARING | KOBBALL Superseded by part number: VI8970256730 |
| 15. | VI8941529780 | [1] | STOPPER SET STOPPER, SET | STOPPER SET STOPPER, SET |
| 16. | VI8944505720 | [1] | CASE, GEAR | |
| 17. | VI8941529800 | [1] | LEVER SET, SHIFT | |
| 18. | VI8941529820 | [1] | COVER KIT | |
| 19. | VI8941529830 | [1] | RETAINER RETAINER, BEARING | RETAINER RETAINER, BEARING |
| 20. | VI8942428710 | [2] | BOLT, THROUGH | |
| 21. | VI9019106160 | [3] | BOLT, M6X16 | |
| 22. | VI9019106370 | [2] | BOLT, M6X37 | |
| 23. | VI8941529810 | [1] | SWITCH | KOBSWITCH ASM., MAGNETIC |
| 24. | VI5811290690 | [1] | COVER, TERMINAL MAGNETIC | |
