神钢零件查询(K903C) - EXCAVATOR ASN LE5701 (1/87-12/03) (01-022[03]) - STARTER (NIKKO) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
668 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8941712961 | [1] | STARTER ASM.,12V-2.2KW | |
| 1. | VI1811290320 | [1] | PIN | |
| 2. | VI9821253410 | [2] | WASHER, SEAL | |
| 3. | VI8941780170 | [1] | LEVER ASM., SHIFT | |
| 4. | VI5094000250 | [1] | NUT | KOB Superseded by part number: 5094000250 |
| 5. | VI8944170180 | [1] | SWITCH ASM., MAG. | |
| 6. | VI8941780260 | [2] | BOLT | |
| 8. | VI8941780270 | [1] | WIRE ASM., LEAD | |
| 9. | VI8941780280 | [1] | TERMINAL ASM. | |
| 10. | VI9881201250 | [1] | WASHER | |
| 11. | VI3941780290 | [1] | BUSH, INSULATE | |
| 12. | VI3941780300 | [1] | SEAT, INSULATE | |
| 13. | VI3941780310 | [1] | BUSH, GUM | |
| 14. | VI3941780320 | [1] | SEAT, INSULATE | |
| 15. | VI3941780330 | [1] | RIVET | |
| 16. | VI3944188630 | [1] | BRACKET ASM., REAR | |
| 17. | VI3941780340 | [1] | BRACKET, REAR | |
| 18. | VI3941780350 | [2] | BOLT | |
| 19. | VI8941780470 | [4] | SPRING, BRUSH | |
| 20. | VI8941780480 | [1] | HOLDER ASM., BRUSH | |
| 21. | VI8944388770 | [1] | BRACKET ASM., FRONT | |
| 22. | VI8941780370 | [1] | SET OF STD MAIN BRGS | KOBMETAL |
| 23. | VI8941712530 | [1] | RING, CLIP | |
| 24. | VI8941712540 | [1] | STOPPER, PINION | |
| 25. | VI8944388780 | [1] | CLUTCH ASM. | |
| 26. | VI8941780410 | [1] | BRACKET ASM., CENTER | |
| 27. | VI8941780420 | [1] | METAL | |
| 28. | VI8941780430 | [1] | WASHER, INSULATE | |
| 29. | VI8941780440 | [1] | SHAFT | |
| 30. | VI5811291600 | [1] | WASHER | |
| 31. | VI5811291590 | [1] | WASHER | |
| 32. | VI5811291580 | [1] | WASHER, INSULATE | |
| 33. | VI8941780450 | [1] | BRACKET, CENTER | |
| 34. | VI8941780460 | [2] | BOLT | |
| 35. | VI5811290240 | [4] | SCREW | |
| 36. | VI8941780490 | [2] | BOLT | |
| 37. | VI5811291560 | [1] | SET OF THRUST WASHER | KOBWASHER |
| 38. | VI8944186670 | [1] | ARMATURE ASM. | |
| 39. | VI1811295310 | [1] | BEARING, BALL | |
| 40. | VI8944188660 | [1] | BEARING | KOBBALL |
| 41. | VI8941780520 | [1] | COIL ASM., FIELD | |
| 42. | VI8941780530 | [2] | BRUSH, (-) | |
| 43. | VI8941780540 | [2] | BRUSH, (+) | |
| 44. | VI8941780550 | [1] | SEAL KIT | |
