神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (02-020) - COVER ASSY, UNDER, P/N 24100J9970F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
697 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J9970F2 | [1] | COVER ASSY,UNDER | |
| 1. | 2414P6323 | [1] | COVER | |
| 2. | 2414P6321 | [1] | COVER | |
| 4. | 2414P6325 | [1] | COVER | |
| 5. | 2414T2884 | [1] | COVER | KOB530 x 230 x Th 2.3mm |
| 7. | 2414P6322 | [1] | COVER | |
| 13. | 2414P6324 | [1] | COVER | |
| 14. | 2414P6326 | [1] | COVER | |
| 15. | 2414P6747 | [1] | COVER | |
| 16. | 2414P6748 | [1] | COVER | |
| 17. | 2420T6787 | [36] | SCREW,M12 x 1.75 x 20mm | KOBM12x1.75x20mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C12030 |
| 18. | 2420T6788 | [4] | SCREW,M10 x 1.5 x 25mm | KOBM10x1.50x25mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C10025 |
