神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (10-006) - TOOL ASSY, P/N 24100N5355F5 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
319 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N5355F5 | [1] | TOOL ASSY | |
| 1. | ZT12A50000 | [1] | POINT | KOBSpanner -- 50mm Long (1-31/32 in) |
| 2. | ZT12A41000 | [1] | ADJUSTING WRENCH | KOBSpanner, 41mm |
| 3. | ZT12A36000 | [2] | SEAT BACK | KOBSpanner, 36mm |
| 4. | ZT12A24000 | [1] | HEATER | KOB24mm |
| 5. | ZT12A19000 | [1] | GEAR | KOBSpanner, 19mm |
| 6. | ZT12A17000 | [1] | PLUG | KOBSpanner, 17mm |
| 7. | ZT12A14000 | [1] | BOX SPANNER | KOB |
| 8. | ZT12A10000 | [1] | PLUG | KOBSpanner, 10mm |
| 9. | 2421Z294 | [1] | BLOCK DRIVER | KOBDRIVER Screw, 165mm Long |
| 10. | ZT31B13250 | [1] | HANDLE | KOB |
| 11. | ZT31D13150 | [1] | BAR | KOB |
| 12. | ZT31A24000 | [1] | SOCKET | KOB |
| 13. | ZT31A22000 | [1] | SOCKET | KOB |
| 14. | ZT31A19000 | [1] | SOCKET | KOB |
| 15. | ZT31A17000 | [1] | SOCKET | KOB |
| 1G. | ZT22A14000 | [1] | KEY | KOB14mm |
| 17. | ZT22A12000 | [1] | KEY, SCREW 12mm | KEY, SCREW 12mm |
| 18. | ZT22A08000 | [1] | KEY | KOBScrew -- 08mm |
| 19. | ZT22A06000 | [1] | KEY, SCREW 06mm | KEY, SCREW 06mm |
| 20. | 2421R145 | [1] | GREASE GUN | KOB Superseded by part number: YT01T01009F1 |
| 21. | ZT12D20000 | [1] | WRENCH, ADJUST 24mm Maximum | WRENCH, ADJUST 24mm Maximum |
| 22. | 2421T8 | [1] | TIGHTENER | KOB |
| 23. | ZT71A15000 | [1] | HAMMER | KOB |
| 24. | 2414T4185 | [1] | TOOL BOX | KOB400x155x110mm |
| 26. | ZT51A15000 | [1] | PLIERS | KOB |
| 27. | 2421R170 | [1] | GENERAL TOOL | KOB Superseded by part number: YW01T01014P1 |
| 28. | 2421R140 | [1] | NOZZLE | KOBAdapter -- 1/8"PFx180mm Long |
| 29. | 2421Z298 | [1] | CAP | KOB |
| 30. | ZT22A10000 | [1] | KEY | KOB10mm |
| 31. | B16T0442D1 | [5] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| 32. | B16T0442D2 | [3] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 33. | B16T0442D29 | [3] | SHIM,130mm OD x 72mm ID x 2.0mm Thk | KOBID 72 x OD 130 x Th 2.0mm |
| 34. | B16T0442D5 | [1] | SHIM,130mm OD x 72mm ID x 2.3mm Thk | KOBID 72 x OD 130 x Th 2.3mm |
| 35. | B16T0442D27 | [3] | SHIM,62mm ID x 100mm OD x 1.2mm Thk | KOBID 62 x OD 100 x Th 1.2mm |
| 36. | B16T0442D19 | [1] | SHIM,62mm ID x 100mm OD x 1.6mm Thk | KOBID 62 x OD 100 x Th 1.6mm |
| 37. | B16T0442D30 | [1] | SHIM,100mm OD x 62mm ID x 2.0mm Thk | KOBID 62 x OD 100 x Th 2.0mm |
| 38. | B16T0442D20 | [1] | SHIM,100mm OD x 62mm ID x 2.3mm Thk | KOBID 62 x OD 100 x Th 2.3mm |
