神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (11-003) - VALVE ASSY, MAIN RELIEF, P/N 2436S682F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
535 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436S682F1 | [1] | VALVE ASSY.MAIN RELIEF | |
| . . | 2436S682F2 | [1] | VALVE ASSY.MAIN RELIEF | |
| . . | 2436S682F3 | [1] | VALVE ASSY.MAIN RELIEF | |
| . . | 2436S682F4 | [1] | VALVE ASSY.MAIN RELIEF | |
| . . | 2436S682F5 | [1] | VALVE ASSY.MAIN RELIEF | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT(F2-F5 ONLY) |
| 2. | 2436R682S2 | [1] | SET OF SCREWS | KOB(F2-F5 ONLY) Superseded by part number: 2436R682S601 |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBODY(F1-F5 ONLY) |
| 102. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG(F1-F5 ONLY) |
| 121. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm, (F2-F5 Only) |
| 141. | ZD12G02500 | [1] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm, (F1-F5 Only) |
| 201. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER(F1-F5 ONLY) |
| 211. | 2436R682S211 | [1] | SPRING | KOB(F1-F5 ONLY) |
| 301. | 2436R682S301 | [1] | SEAT(F1&F2 ONLY) | |
| 311. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT,SPRING(F2-F5 ONLY) |
| 312. | NSS | [1] | NOT SOLD SEPARAT | CONFILTER(F2-F5 ONLY) |
| 401. | 2436R682S401 | [1] | POPPET | KOB(F1-F5 ONLY) |
| 511. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING(F1-F5 ONLY) |
| 521. | 2436R682S521 | [1] | SEAT | KOBSPRING(F1-F5 ONLY) |
| 531. | ZD12P00600 | [1] | O-RING | KOBID 05.80 ± 0.15 x OD 09mm, (F1-F5 Only) |
| 601. | 2436R682S601 | [1] | SET OF SCREWS | KOB(F1 ONLY) |
| 611. | 2436R683S671 | [1] | NUT | KOB(F1-F5 ONLY) Superseded by part number: ZN18C12007 |
