神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (11-007) - VALVE ASSY, RELIEF, P/N 2436R727F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
785 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R727F1 | [1] | VALVE PRESSURE RELIE | KOBASSY |
| . . | 2436R727F3 | [1] | VALVE PRESSURE RELIE | KOBASSY |
| . . | 2436R727F4 | [1] | VALVE PRESSURE RELIE | KOBASSY |
| . . | 2436R727F5 | [1] | VALVE | KOB |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBODY(F5 ONLY) |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBODY(F1,F3,F4 ONLY) |
| 201. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG(F1.F3-F5 ONLY) |
| 261. | ZD12G02500 | [1] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm, (F1.F3-F5 Only) |
| 262. | ZD85G02500 | [1] | BACK-UP RING | KOBRing, Back-Up -- ID 25 x OD 30 x Th 1.25mm, (F1.F3-F5 Only) |
| 291. | NSS | [1] | NOT SOLD SEPARAT | CONRING,LOCK(F1.F3-F5 ONLY) |
| 301. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER(F1.F3-F5 ONLY) |
| 302. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON(F1.F3-F5 ONLY) |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON(F1.F3-F5 ONLY) |
| 311. | NSS | [1] | NOT SOLD SEPARAT | CONBALL(F1.F3-F5 ONLY) |
| 321. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING, (F1.F3-F5 ONLY) |
| 322. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING, (F1.F3-F5 ONLY) |
| 323. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING, (F1.F3-F5 ONLY) |
| 331. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT,(F1.F3-F5 ONLY) |
| 341. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT(F1.F3-F5 ONLY) |
| 342. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING(F1.F3-F5 ONLY) |
| 343. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT,(F1.F3-F5 ONLY) |
| 361. | NSS | [1] | NOT SOLD SEPARAT | CONO-RING(F1.F3-F5 ONLY) |
| 362. | NSS | [1] | NOT SOLD SEPARAT | CONRING,BACK-UP(F1.F3-F5 ONLY) |
| 471. | NSS | [1] | NOT SOLD SEPARAT | CONBOLT,ADJUST(F1.F3-F5 ONLY) |
| 473. | NSS | [1] | NOT SOLD SEPARAT | CONNUT,LOCK(F1.F3-F5 ONLY) |
| 851. | 2436R686S851 | [1] | CAP | KOB(F1.F3-F5 ONLY) |
