神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (11-010) - VALVE ASSY, RELIEF, P/N 2436R771F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
512 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R771F1 | [1] | VALVE ASSY, RELIEF | |
| 266. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 308. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 309. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 344. | NSS | [1] | NOT SOLD SEPARAT | CONSLEEVE |
| 346. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING |
| 347. | 2436R771S347 | [1] | STOPPER | |
| 356. | 2436R771S356 | [1] | PLUG | |
| 362. | ZD12P00900 | [1] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 375. | 2436R771S375 | [1] | SPRING | |
| 376. | 2436R771S376 | [1] | WASHER | KOB |
