神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (11-022) - VALVE ASSY, CONTROL, P/N 2436U1210F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
661 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1210F1 | [1] | VALVE, CONTROL | VALVE, CONTROL |
| . . | 2436U1210F2 | [1] | CONTROL VALVE | KOB |
| 1. | B36K0019E112 | [4] | NUT | KOB(F1,F2 ONLY) |
| 2. | 2436U428S5 | [2] | TIE-ROD(F1,F2 ONLY) | |
| 3. | B36K0019E110 | [2] | NUT | KOB(F1,F2 ONLY) |
| 4. | 2436U836S4 | [1] | TIE-ROD(F1,F2 ONLY) | |
| 5. | 2436Z416F1 | [1] | SECTION ASSY, INLET (SEE.P.2436Z416-1,2)(F1,F2 ONLY) | SECTION ASSY, INLET (SEE.P.2436Z416-1,2)(F1,F2 ONLY) |
| 7. | 2436R806F1 | [1] | SPOOL | KOB(SEE.P.2436R806-1,2)(F1,F2 ONLY) |
| 8. | 2436R721F1 | [1] | VALVE PRESSURE RELIE | KOBSEE.P.2436R721-1,2(F1) |
| 9. | 2420Z1267F1 | [1] | PLUG ASSY(F1,F2 ONLY) | |
| 9-1. | 2420Z1267S1 | [1] | PLUG(F1,F2 ONLY) | |
| 9 2. | 2436R282S1 | [1] | O-RING | KOB(F1,F2 ONLY) Superseded by part number: 2436U388S42 |
| 10. | 2420Z1268F1 | [1] | PLUG ASSY(F1,F2 ONLY) | |
| 10 1. | 2436U1956S22 | [1] | PLUG (F1,F2 ONLY) | PLUG (F1,F2 ONLY) |
| 10-2. | 2436U618S13 | [1] | O-RING | KOB(F1,F2 ONLY) |
| 11. | 2436U1210S11 | [1] | TUBE ASSY(F1,F2 ONLY) | |
| 12. | 2420Z1264F1 | [1] | PLUG ASSY(F1,F2 ONLY) | |
| 12-1. | 2420Z1264S1 | [1] | PLUG(F1,F2 ONLY) | |
| 12-2. | 2445Z7D8 | [1] | O-RING | KOB(F1,F2 ONLY) Superseded by part number: 921206 |
| 12-3. | 2420Z1264S3 | [1] | O-RING(F1,F2 ONLY) | |
| 12-4. | 2420Z1264S4 | [1] | RING,BACK-UP(F1,F2 ONLY) | |
| 13. | 2420Z126SF1 | [1] | PLUG ASSY(F1,F2 ONLY) | |
| 13-1. | 2420R912S1 | [1] | PLUG(F1,F2 ONLY) | |
| 13-2. | 2436R718S11 | [1] | O-RING | KOBO-RING (F1,F2 ONLY) Superseded by part number: ZD12P02900 |
