神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (11-024) - VALVE ASSY, CONTROL, P/N 2436U1217F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
920 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1217F2 | [1] | CONTROL VALVE | KOB |
| 1. | B36K0019E112 | [4] | NUT | KOB |
| 2. | 2436U428S5 | [2] | ROD,TIE | |
| 3. | B36K0019E110 | [2] | NUT | KOB |
| 4. | 2436U836S4 | [1] | ROD,TIE | |
| 5. | 2436Z416F1 | [1] | SECTION ASSY, INLET (SEE.P.2436Z4161 1.2 | SECTION ASSY, INLET (SEE.P.2436Z4161 1.2 |
| 6. | 2436U1210S6 | [1] | SECTION ASSY,OUTLET | |
| 7. | 2436R805F1 | [1] | SPOOL ASSY(SEE.P.2436R805-1 ,2) | |
| 8. | 2436R721F1 | [2] | VALVE PRESSURE RELIE | KOB(SEE.P.2436R721-1 ,2 |
| 9. | 2420Z1267F1 | [1] | PLUG ASSY | |
| 9-1. | 2420Z1267S1 | [1] | PLUG | |
| 9-2. | 2436R282S1 | [1] | O-RING | KOB Superseded by part number: 2436U388S42 |
| 10. | 2420Z1268F1 | [1] | PLUG ASSY | |
| 10-1. | 2436U1956S22 | [1] | PLUG | PLUG |
| 10-2. | 2436U618S13 | [1] | O-RING | KOB |
| 11. | 2436U1210S11 | [1] | TUBE ASSY | |
| 12. | 2420Z1264F1 | [1] | PLUG ASSY | |
| 12-1. | 2420Z1264S1 | [1] | PLUG | |
| 12-2. | 244SZ7D8 | [1] | O-R1NG | |
| 12-3. | 2420Z1264S3 | [1] | O-RING | |
| 12-4. | 2420Z1264S4 | [1] | RING.BACK-UP | |
| 13. | 2420Z1265F1 | [1] | PLUG ASSY | |
| 13-1. | 2420R912S1 | [1] | PLUG | |
| 13-2. | 2436R718S11 | [1] | O-RING | KOBO-RING Superseded by part number: ZD12P02900 |
| 14. | 2420Z1270F1 | [1] | PLUG ASSY | |
| 14-1. | 2436U388S19 | [1] | PLUG | KOB |
| 14-2. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
