神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (11-025) - VALVE ASSY, CONTROL, P/N 2436U1236F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
593 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1236F1 | [1] | VALVE, CONTROL | VALVE, CONTROL |
| 1. | 2436Z416F1 | [1] | SECTION ASSY, INLET (SEE.P.2436Z416-1,2) | SECTION ASSY, INLET (SEE.P.2436Z416-1,2) |
| 2. | B36K0019E102 | [1] | SECTION ASSY,OUTLET | |
| 3. | 2436R593F1 | [1] | PLUNGER | KOB(SEE.P.2436R593-1 .2 ) |
| 4. | 2436R807F1 | [1] | SPOOL | KOB(SEE.P.2436R807-1 .2 ) |
| 5. | 2436R1094F1 | [1] | VALVE | KOB(SEE.P.2436R1094- 1.2 ) |
| 6. | 2436R721F3 | [4] | HYDRAULIC VALVE | KOB(SEE.P.2436R721-1,2) |
| 7. | 2420Z1266F1 | [1] | PLUG | KOB |
| 7-1. | 2420Z1266S1 | [1] | PLUG | |
| 7-2. | 2436U618S28 | [1] | O-RING | KOB Superseded by part number: ZD12P02400 |
| 7-3. | 2483U283S9 | [1] | O-RING | KOB Superseded by part number: ZD12P01100 |
| 7-4. | 2420Z1266S4 | [1] | PLUG | |
| 8. | B36K0019E112 | [4] | NUT | KOB |
| 9. | 2436U790S9 | [2] | TIE-ROD | KOB |
| 10. | 2436U281S8 | [2] | NUT | NUT |
| 11. | 2436U790S11 | [1] | TIE-ROD | KOB |
