现代零件查询R36N-7 SLEW MOTOREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
1003 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-03718
|
[1] |
SLEW MOTOR
|
|
| 101. |
XJDH-03719
|
[1] |
SEAL KIT
|
|
| 102. |
XJDH-03720
|
[1] |
X-RING
|
|
| 103. |
XJDH-03721
|
[3] |
O-RING
|
|
| 104. |
XJDH-03722
|
[1] |
O-RING
|
|
| 105. |
XJDH-03723
|
[1] |
SEAL-SHAFT FACE
|
|
| 106. |
XJDH-03724
|
[1] |
SEAL-INNER FACE
|
|
| 107. |
XJDH-03377
|
[1] |
O-RING
|
|
| 108. |
XJDH-03753
|
[2] |
O-RING
|
|
| 109. |
XJDH-03733
|
[2] |
O-RING
|
|
| 110. |
XJDH-03183
|
[1] |
O-RING
|
|
| 111. |
XJDH-03734
|
[2] |
O-RING
|
|
| 112. |
XJDH-03735
|
[1] |
SEAL KIT
|
|
| 113. |
XJDH-03736
|
[2] |
O-RING
|
|
| 114. |
XJDH-03737
|
[2] |
SEAL-CAP
|
|
| 115. |
XJDH-03304
|
[2] |
O-RING
|
|
| 116. |
XJDH-03738
|
[2] |
O-RING
|
|
| 117. |
XJDH-03739
|
[4] |
RING-BACK UP
|
|
| 118. |
XJDH-00332
|
[2] |
O-RING
|
|
| 2. |
XJDH-00086
|
[3] |
BOLT
|
|
| 3. |
XJDH-00085
|
[1] |
BOLT
|
|
| 4. |
XJDH-00283
|
[4] |
WASHER
|
|
| 5. |
XJDH-00452
|
[3] |
CONNECTOR-MALE
|
|
| 6. |
XJDH-00495
|
[1] |
TEE
|
|
