神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (11-028) - VALVE ASSY, SELECTOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
498 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1244F1 | [1] | VALVE | KOBSELECTOR(MULTl MODE) |
| 1. | 2436U12448100 | [1] | SPOOL ASSY.CASING(CONSISTS OF Ref: 101,301.351) | |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCASING |
| 161. | ZD12G08000 | [2] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOBID 79.40 ± 0.69 x OD 85mm |
| 201. | 2436U1244S201 | [1] | COVER | KOB |
| 202. | 2436U1244S202 | [1] | COVER | KOB |
| 211. | 2441U732S693 | [1] | BALL | |
| 221. | 2436U1244S221 | [1] | SPRING | KOB |
| 261. | 2436U1244S261 | [1] | SEAL | KOB |
| 271. | ZS23C08035 | [6] | SCREW,Hex Socket Head, M8 x 35mm | KOBM08x1.25x35mm |
| 272. | ZS23C08030 | [6] | SCREW,Hex Socket Head, M8 x 30mm | KOBM08x1.25x30mm Superseded by part number: ZS28C08030 |
| 274. | 2436U1244S274 | [2] | SPACER | KOB |
| 301. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 351. | NSS | [16] | NOT SOLD SEPARAT | CONCAPSCREW |
| 401. | 2436U1244S401 | [1] | PIN | KOB |
| 402. | 2436U1244S402 | [1] | LEVER | KOB |
| 403. | 2436U1244S403 | [1] | KNOB | KOB |
| 461. | ZD12P02800 | [1] | O-RING | KOBID 27.70 ± 0.27 x OD 34mm |
| 462. | ZD85P02800 | [1] | BACK-UP RING | KOBRING, BACK-UP |
| 471. | 2436U1244S471 | [1] | ROLL PIN | KOBPIN,SPRING Superseded by part number: ZP26D06025 |
| 472. | 2436U1244S472 | [1] | SCREW | KOBBOLT,LOCKING Superseded by part number: 2436U1244S50 |
| 473. | 2436D1244S473 | [1] | SPACER | |
| 901. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
