| . . | 2436U1252F1 | [1] | VALVE ASSY (MB) CONTROL (SWING) | VALVE ASSY (MB) CONTROL (SWING) |
| . . | 2436U1252F2 | [1] | X | KOB(MB) CONTROL (SWING) |
| . . | 2436U1252F3 | [1] | X | KOB(MB) CONTROL (SWING) |
| 1. | 2436R727F4 | [2] | VALVE PRESSURE RELIE | KOB(SEE.P.2436R727-1 .2 )(F2 ONLY) |
| 2. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING(F2 ONLY) |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL(F3 ONLY) |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING(F3 ONLY) |
| 5. | 2436R727F5 | [2] | VALVE | KOB(SEE.P.2436R727-1 .2 )(F3 ONLY) |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCASING(F1-F3 ONLY) |
| 151. | 2436U1165S154 | [2] | PLUG | KOB(F1-F3 ONLY) |
| 152. | 2441U732S461 | [1] | PLUG | KOBPLUG(F1-F3 ONLY) Superseded by part number: 2436U2080S8 |
| 153. | 2436U1219S153 | [1] | PLUG | KOB(F1-F3 ONLY) |
| 161. | ZD12G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm, (F1-F3 Only) |
| 162. | 2436U665S262 | [2] | O-RING | KOB(F1-F3 ONLY) Superseded by part number: 2436U1457S162 |
| 163. | ZD12P00700 | [2] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm, (F1-F3 Only) |
| 164. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm, (F1-F3 Only) |
| 165. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm, (F1-F3 Only) |
| 166. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm, (F1-F3 Only) |
| 171. | ZS23C12110 | [6] | SCREW,Hex Socket Head, M12 x 110mm | KOBM12x1.75x110mm, (F1-F3 Only) Superseded by part number: ZS28C12110 |
| 201. | 2436U1745S201 | [1] | COVER.SPRING(F1-F3 ONLY) | |
| 202. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER.VALVE(F1-F3 ONLY) |
| 211. | NSS | [1] | NOT SOLD SEPARAT | CONBALL(F1-F3 ONLY) |
| 231. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT(F1-F3 ONLY) |
| 251. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG(F1-F3 ONLY) |
| 253. | 2441U722S466 | [1] | PLUG | KOB(F1-F3 ONLY) Superseded by part number: 2441U667S466 |
| 261. | NSS | [1] | NOT SOLD SEPARAT | CONO-RING(F1-F3 ONLY) |
| 271. | ZS23C06025 | [4] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm, (F1-F3 Only) |
| 272. | ZS23C06040 | [4] | SCREW,Hex Socket Head, M6 x 40mm | KOBM06x1.0x40mm, (F1-F3 Only) |
| 301. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL(F1-F2ONLY) |
| 321. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING(F1-F2 ONLY) |
| 331. | NSS | [2] | NOT SOLD SEPARAT | CONSEAT,SPRING(F1-F3 ONLY) |
| 332. | NSS | [1] | NOT SOLD SEPARAT | CONBOLT,SPACER(F1-F3 ONLY) |
| 511. | NSS | [3] | NOT SOLD SEPARAT | CONPOPPET(F1-F3 ONLY) |
| 512. | NSS | [2] | NOT SOLD SEPARAT | CONPOPPET(F1-F3 ONLY) |
| 521. | NSS | [3] | NOT SOLD SEPARAT | CONSPRING(F1-F3 ONLY) |
| 522. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING(F1,F3 ONLY) |
| 551. | NSS | [5] | NOT SOLD SEPARAT | CONPLUG(F1-F3 ONLY) |
| 561. | NSS | [5] | NOT SOLD SEPARAT | CONO-RING(F1-F3 ONLY) |
| 601. | 2436R727F3 | [2] | VALVE PRESSURE RELIE | KOB(SEE.P.2436R727-1, 2 )(F1 ONLY) |
| 901. | NSS | [1] | NOT SOLD SEPARAT | CONNAHE-PLATE(F1-F3 ONLY) |
| K. | 2436U1252R100 | [1] | REPAIR KIT | KOB(CONSISTS OF Ref:101.301,321.331.332.511. 512.521.522.551.561 ) |
| K. | 2436U1252R200 | [1] | N/A REPAIR KIT (CONSISTS OF Ref: 202.211.231.251,261) | N/A REPAIR KIT (CONSISTS OF Ref: 202.211.231.251,261) |
| K. | 2436U1252R300 | [1] | REPAIR KIT | KOB(CONSISTS OF Ref: 2. 101.301.321.331.332. 511.512.521.551.561) |
| K. | 2436U1252R400 | [1] | REPAIR KIT (CONSISTS OF Ref: 3, 4, 101.331.332.511. 512.521,522.551.561 ) | REPAIR KIT (CONSISTS OF Ref: 3, 4, 101.331.332.511. 512.521,522.551.561 ) |
