神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (11-047) - CYLINDER ASSY (DOZER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
725 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U738F1 | [1] | CYLINDER | KOBCYLINDER ASSY (DOZZER) |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONTUBE,CYLINDER |
| 2. | 2438U515S2 | [2] | BUSHING | KOB |
| 3. | 2438U697S10 | [4] | SEAL | KOBDUST Superseded by part number: 2445R138D3 |
| 4. | 2438U738S4 | [1] | PISTON | KOB |
| 5. | 2438U738S5 | [1] | PISTON | KOB |
| 6. | 2438U504S7 | [1] | SEAL | KOB |
| 7. | 2438U504S8 | [1] | O-RING | KOB |
| 8. | R45T0098D1 | [1] | PISTON RING | KOB |
| 9. | ZD12G06500 | [1] | O-RING,64.40mm ID x 70.60mm OD x 3.10mm | KOBID 64.40 ± 0.57 x OD 70mm |
| 10. | 2433U738S10 | [1] | NUT, PISTON | |
| 11. | 2438U738S11 | [1] | RING | |
| 12. | 2438U738S12 | [1] | COVER ASSY | KOBCOVER,ROD |
| 13. | 2438U515S13 | [1] | BUSHING | KOB Superseded by part number: 2405U104D065060 |
| 14. | B38K0038E10 | [1] | CLIP | KOB |
| 15. | ZD12P10000 | [1] | O-RING | KOBID 99.60 ± 0.84 x OD 110mm |
| 16. | 2438U554S20 | [1] | RING BACK UP | |
| 17. | ZD12G10500 | [1] | O-RING,104.40mm ID x 110.60mm OD x 3.10mm | KOBID 14.80 ± 0.20 x OD 19mm |
| 20. | R45P0050D6 | [1] | SEAL | KOB |
| 21. | 45Z91D16 | [1] | O-RING | KOBID 69.22 ± 0.38 OD 79.88mm |
| 22. | 2438U286S31 | [1] | KIT | KOB |
| 23. | B38K0024E8 | [1] | DUST CAP | KOB Superseded by part number: 2418U131D14 |
| 24. | B38K0039E11 | [1] | CLAMP | KOB |
| 25. | 2438U257E10 | [1] | LOCK WASHER | KOB |
| 26. | 2438U738S26 | [2] | RING BACK UP | |
| 27. | 2438U738R100 | [1] | REPAIR KIT | KOBREPAIR KIT CONSISTS OF ITEM 15,16.17 &20- 23 |
| 28. | 2438U738R200 | [1] | REPAIR KIT | KOBREPAIR KIT CONSISTSOF ITEM 6, 7. 8. 9 |
