神钢零件查询(K904) - MARK II EXCAVATOR ASN YW1119 (1/88-12/03) (11-050) - CYLINDER ASSY (ARM), P/N 2438U973F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
442 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U973F1 | [1] | CYLINDER | KOB |
| . . | NSS | [1] | NOT SOLD SEPARAT | CON |
| 1. | 2438U973S1 | [1] | BARREL | KOB |
| 2. | 2438U309S2 | [2] | BUSHING | KOB |
| 3. | 2445R138D6 | [4] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| 4. | 2438U973S4 | [1] | PISTON ROD | KOB |
| 5. | 2438U973S5 | [1] | PISTON | KOB |
| 6. | 2438U695S6 | [1] | SEAL | KOBSEAL Superseded by part number: R45P0049D2 |
| 7. | R45P0051D4 | [1] | O-RING | KOB |
| 8. | R45T0098D3 | [2] | RING | KOB |
| 9. | 2438U973S9 | [2] | RING | KOB |
| 10. | 2438U995S11 | [1] | NUT | KOB |
| 11. | 2438U308S45 | [1] | LOCKING RING | KOB |
| 12. | ZD12G07000 | [1] | O-RING,69.40mm ID x 75.60mm OD x 3.10mm | KOBID 69.40 ± 0.61 x OD 75mm |
| 13. | ZD75G07000 | [2] | BACK-UP RING | KOB |
| 14. | 2438U973S14 | [1] | RING | KOB |
| 15. | 2438U973S15 | [1] | AIR CONDITIONER | KOB |
| 16. | ZD12G12000 | [1] | O-RING,3.1mm Thk x 119.4mm ID, 90 Duro | KOBO-Ring -- ID 119.40 ± 0.98 x OD 125mm |
| 17. | ZD12G11000 | [2] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOBID 109.4 ± 0.91 x OD 115mm |
| 18. | ZD85P11000 | [2] | BACK-UP RING | KOB |
| 19. | 2438U393S12 | [1] | BUSHING | KOB |
| 20. | 2438U718S22 | [1] | CLIP | KOB |
| 21. | R45P0050D9 | [1] | RUBBER SEAL | KOB |
| 22. | 45Z91D44 | [1] | O-RING | KOB |
| 23. | 2418U130D34 | [1] | PACKING | KOB Superseded by part number: Y0496604500 |
| 24. | 2438U928S24 | [1] | DUST CAP | KOB Superseded by part number: 2438U928S33 |
| 28. | 2438U973S28 | [1] | VALVE | KOB |
| 29. | 2438U921S32 | [1] | SPRING | KOB |
| 30. | 2438U921S28 | [1] | SPACER | KOB |
| 31. | ZE82T06000 | [1] | PLUG | KOBPipe, 3/8" PT |
| 32. | ZS23C14055 | [12] | SCREW,Hex Socket Head, M14 x 55mm | KOBM14x2.0x55mm |
| 33. | 2438U928S26 | [1] | CLAMP | KOB |
| 34. | 2438U915S22 | [1] | BAND | KOB |
| 35. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 36. | ZS16C10035 | [2] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| . . | 2438U973R100 | [1] | REPAIR KIT | KOB Superseded by part number: 2438U973R100P |
| . . | 2438U973R200 | [1] | REPAIR KIT | KOB Superseded by part number: 2438U1132R200 |
| . . | 2438U973R300 | [1] | REPAIR KIT | REPAIR KIT |
