凯斯零件查询(LB424S XL) - BALER (11/16-) (31.220.110) - MAIN GEARBOX, ARM TO PLUNGER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
826 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84074507
|
[1] |
CAP
|
ZED
|
| 2. |
412270
|
[2] |
SNAP RING,M120 x 4mm Thk, Internal
|
ZED
|
| 3. |
84074500
|
[2] |
CIRCLIP
|
ZED
|
| 4. |
47361017
|
[2] |
ROLLER BEARING,65mm ID x 120mm OD x 31mm W
|
ZED
|
| 5. |
84346501
|
[2] |
HUB
|
ZED
, Serial Range: -C144 Superseded by part number: 47706699
|
| 5. |
47706699
|
[2] |
HUB
|
ZED
, Start Serial: D145
|
| 6. |
84074502
|
[2] |
THRUST WASHER,100.5mm ID x 119.5mm OD x 1mm Thk
|
ZED
|
| 7. |
84074504
|
[2] |
SEALING RING
|
ZED
|
| 8. |
84346544
|
[1] |
ARM
|
ZED
|
| 9. |
84346525
|
[4] |
SCREW,M24 x 200mm, Cl 12.9
|
ZED
|
| 10. |
84346530
|
[4] |
WASHER
|
ZED
Superseded by part number: 84074425
|
| 11. |
84074506
|
[1] |
SEALING RING
|
ZED
|
| 12. |
84346542
|
[1] |
ARM
|
ZED
|
| 13. |
84346543
|
[1] |
CRANK
|
ZED
Incl 8, 5, Serial Range: -C144
|
| 13. |
47706702
|
[1] |
ARM
|
ZED
Incl 8, 5, Start Serial: D145
|
| 14. |
84346541
|
[1] |
CRANK
|
ZED
Incl 12, 5, Serial Range: -C144
|
| 14. |
47706701
|
[1] |
ARM
|
ZED
Incl 12, 5, Start Serial: D145
|
